XCMG XCT50_Y

XCMG Manufacturer XCT50_Y 50 Ton Mobile Truck Crane.

1XCT50_Y Truck crane is widely used for the lifting operations in general engineering projects, such as construction site, urban renewal, communication and transportation, ports, bridge, oilfields and mine, and complex working environments.
2Dual-pump confluence technology is applied to the crane movements, such as hook up / hook down, boom out, as well as boom up, so that the working efficiency of elevating and telescoping operation gets ahead of all competing cranes.
3Automatic planning technology of working conditions .Automatic recommendation of optimum working condition
4Improved adaptation for Southeast Aaia region
5High-power air conditioner is available in the operators cab with improved cooling effect
65-section boom of 44m with U-type profile is adopted; the max. lifting load is 50 t; the max. lifting height is 59.5 m; all capacities take the lead in its class.
7Diesel engine, with rated power of 247kW, and max. torque of 1600N.m
8Max. travel speed is 90 Km/h, and Max. grade ability is 40%
9Foot pedal operated double-circuit air pressure brake. The disc brakes are used for the first axle, drum brakes are used for the 2nd and 3rd axles.
10Slewing speed 0-2 r/min
11Max. hoisting 128m/min
12Waterproof connectors, with rubber sleeve, protection level IP67.
