2025 MAGNI THA 3.6

With a 3-ton capacity and 5.8-meter height, the new THA 3.6 combines compact dimensions and high performance. The most compact fixed agricultural telehandler in the THA range, intended for the agricultural sector , it can lift a full load to a height of 5.4 meters, 2,500 kg at maximum height, and 1,000 kg at over 3 meters of horizontal outreach. Thanks to its low-profile design, it is ideal for confined spaces while maintaining optimal ground clearance for rough terrain.

Specifications:
o Stabilizers: None
o Lifting capacity: 3,000 kg
o Capacity at maximum height: 2,500 kg
o Lifting height: 5.80 m
o Reach: 3.50 m
o Engine: Deutz TD 2,9 L4 EDG - Stage IIIA
o Rated power: 55,40 kW (75,30 hp) 2.600 rpm
o Number of gears: 2/2
o Hydraulic system: 255 bar (Load Sensing)
o Length: 3.7 m
o Width: 1.8 m
o Ground clearance: 380 mm
o Travel speed: 35 km/h
